Sod Cutter Ryan Jr 18"


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Call For Quote

Weekly: Call For Quote

Monthly: Call For Quote

Quantity:

Additional Information

POWER Honda Engine Model
4-Cycle Honda GX160; recoil start; on/off switch; low-oil alert
Displacement 9.9 cu in. (163 cc)
Fuel Capacity 0.82 gal. (3.1 L)
Oil Capacity 0.61 qt (0.58 L)
Displacement 12.5 cu in. (205 cc)
Fuel Capacity 0.87 gal. (3.3 L)
Oil Capacity 0.63 qt (0.6 L)
UNIT Clutch Spring-loaded belt tightener
Drive V-belt engine to gear case; double roller chain to
blade eccentric shaft; gears and roller chain to traction
wheels; transmission has separate dog clutches to
engage cutting blade and traction drive
Drive Wheel (2) 8 in. (203 mm) diameter, knob tread;
rubber-vulcanized to cast-iron hubs
Lubrication Oil splash in gear case
Speed Up to 135 ft/min (41 m/min)
Cutting Width 12 in. (305 mm) or 18 in. (457 mm)
Cutting Thickness Adjustable up to 2.5 in. (64 mm)
DIMENSIONS
Weight/Wet: 12 in Model 333 lb (151 kg)
Weight/Wet: 18 in Model 373 lb (169 kg)
Width 25 in. (635 mm)
Length 53 in. (1,346 mm)
Height 40 in. (1,016 mm)

* Please call us for any questions on our sod cutter ryan jr 18 inch serving Baker City, Island City, Pendleton OR, and Pasco WA, serving Eastern Oregon.
