Earth-Track Hoes

Excavator Link Belt 240 X2 (Long Boom)


	Image for reference only Actual item may look different Click on image for larger view

Daily: Call For Quote

Weekly: Call For Quote

Monthly: Call For Quote

Quantity:

Additional Information

Max Cutting Height 45.8 ft (14 m)
Max Digging Depth 47.8 ft (15 m)
Max Loading Height 38.7 ft (12 m)
Max Reach Along Ground 59.8 ft (18 m)
Max Vertical Wall Digging Depth 39.8 ft (12 m)
Shipping Height of Unit 10.3 ft (3 m)
Shipping Length of Unit 47.2 ft (14 m)
Bucket
Maximum Bucket Capacity 0.9 cu yds (1 m)
Minimum Bucket Capacity 0.5 cu yds (0 m)
Reference Bucket Capacity 0.5 cu yds (0 m)
Dimensions
Ground Clearance 1.6 ft (0 m)
Height - Top of Cab 9.9 ft (3 m)
Length of Track on Ground 12.6 ft (4 m)
Removal Counterweight Clearance 3.7 ft (1 m)
Tail Swing Radius 9.7 ft (3 m)
Width to Outside of Tracks 11.2 ft (3 m)
Engine
Aspiration Turbocharged
Displacement 317.4 cu in (0 m)
Engine Model AH-4HK1X
Max Torque 469 lbs/ft
Net Power 177 hp (132 kw)
Power Measured @ 2000 rpm
Torque Measured @ 1500 rpm
Operating Specifications
Alternator Supplied Amperage 50 A
Cooling System Fluid Capacity 6.7 gal (25 l)
Engine Oil Capacity 6.2 gal (23 l)
Fuel Capacity 108.4 gal (410 l)
Hydraulic Pump Flow Capacity 123.6 gal/min (468 l/min)
Hydraulic System Fluid Capacity 66.1 gal (250 l)
Hydraulic System Relief Valve Pressure 4970 psi
Operating Voltage 24 V
Operating Weight 61729 lbs (28,000 kg)
Swing Drive Fluid Capacity 2.6 gal (10 l)
Swing Mechanism
Swing Speed 10.7 rpm
Undercarriage
Ground Pressure 6.1 psi
Max Travel Speed 3.4 mph (5 kph)
Number of Carrier Rollers per Side 2
Number of Shoes per Side 51
Number of Track Rollers per Side 9
Shoe Size 31.5 in (80 cm)
Track Gauge 8.5 ft (3 m)
